650719-C (en) Page 7 of 8
116 111 115 112 109 113 114 110
195 123
121
43
196
105
107
101
195
104
102
103
104
126
119
105
117
107
201
127
121
123
118
122
128
112
108
109
110
120
114
113
111
115 116
LEGS
PARTS LIST / 650719-C AIR MOTOR SECTION
) ASSEMBLY TORQUE REQUIREMENTS (
NOTE: DO NOT OVERTIGHTEN FASTENERS.
(105) Screws, 40 - 50 in. lbs (4.5 - 5.6 Nm).
LUBRICATION / SEALANTS
c Apply Key-Lube grease to all “O” rings, “U” cups and
mating parts.
d Apply Loctite 271 to threads.
e Apply Loctite 262™ to threads.
f Apply Loctite 572™ to threads.
Figure 4
MAJOR VALVE CROSS SECTION DETAIL
MAJOR VALVE
See cross section detail, fi gure 4.
Figure 3
PILOT VALVE
IMPORTANT
BE CERTAIN TO ORIENT (115) SPACER LEGS
AWAY FROM BLOCKING INTERNAL PORTS
WHEN REASSEMBLING AIR SECTION.
