InFocus IN5122 - Manual (Page 81)

79
Configure the following items via a web browser to use SNMP.
Example
: If the IP address of the projector is set to 192.168.1.10:
1) Enter “http://192.168.1.10/” into the address bar of the web browser.
2) Enter your user name and password, and then click [OK].
3) Click [Port Settings] on the main menu.
4) Click [Download MIB file] to download a MIB file.
5) Click [Enable] to open the SNMP Port. Set the IP address to send the SNMP
trap to when a Failure/Warning occurs.
6) Click [Security Settings] on the main menu.
7) Click [SNMP] and set the community name on the screen that is displayed.
8) Configure the settings for Trap transmission of Failures/Warnings. Click
[Alert Settings]
on the main menu and select the Failure/Warning item to be
configured.
9) Click [Enable] to send out the SNMP trap for Failures/Warnings. Clear the
[Enable]
checkbox when SNMP trap transmission is not required.
10) Click [Apply] button to save the settings.
7.2 Projector Management using SNMP
The SNMP (Simple Network Management Protocol) enables you to manage the
projector from a computer on the network. The SNMP management software must
be installed on the computer to use this feature.
• It is recommended that SNMP features be carried out by a network
administrator.
• SNMP management software must be installed on the computer to be able to
monitor the projector via SNMP.
• To use the downloaded MIB file, specify the file using your SNMP
manager.
NOTE
NOTE
SNMP Settings (&50)
7. Other Features
• A Network Restart is required after the Community name has been
changed. Click [Network Restart] and configure the following items.
NOTE
• A Network Restart is required after the SNMP Port configuration
settings have been changed. Click [Network Restart] and configure the
following items.
NOTE
