PARTS LIST / LM2305A-XX-B
Item Description (size) Qty Part No. [Mtl] Item Description (size) Qty Part No. [Mtl]
1 Carriage Bolt (1/4” - 20 x 9” long) (4) 94333 [C]
2 Upper Cap (1) 94390 [Z]
n
3 Gasket (2) 94392 [B]
4 Sleeve (2) 94316 [Br]
n
5 “O” Ring (1/16” x 11/16” o.d.) (4) Y325-15 [B]
n
6 “O” Ring (1/8” x 3/4” o.d.) (4) Y325-206 [B]
7 Spool (2) 94310 [D]
n
8 “U” Cup (1/8” x 3/4” o.d.) (2) Y240-7 [B]
n
9 “O” Ring (0.106” x 0.587” o.d.) (2) 15066-PM [B]
10 Cylinder (1) 94306 [A]
n
11 “O” Ring (1/16” x 7/16” o.d.) (1) Y325-11 [B]
12 Adapter - LM2305A-X1-B (1) 94384 [C]
- LM2305A-X2-B (1) 94384-1 [C]
n
13 “O” Ring (1/16” x 3/4” o.d.) (1) Y325-16 [B]
15 Muffler Housing (1) 94443 [A]
16 Foam Liner (2) 94402
17 Edge Trim (2) 94378-1 [N]
18 Retaining Ring (1) 94406 [C]
19 Washer (1) 94515 [C]
n
20 “U” Cup (3/16” x 3” o.d.) (2) 94518 [B]
21 Piston (1) 94403 [D]
22 Lower Cap (1) 94391 [Z]
n
23 “O” Ring (1/8” x 1-9/16” o.d.) (1) Y325-219 [B]
n
24 “O” Ring (3/32” x 2-1/8” o.d.) (1) Y325-135 [B]
25 Bushing (1) 94387 [C]
n
26 Packing
(3/8” x 1-13/16” o.d.)
(1) 94405 [U]
n
27 “O” Ring (3/32” x 1” o.d.) (1) Y325-117 [B]
28 Piston Rod (10.451” long) (1) 94386 [C]
29 Rod - LM2305A-1X-B (1” long) (1) Y23-191 [C]
- LM2305A-3X-B (21-7/32” long) (1) 94450-3 [C]
- LM2305A-4X-B (30-31/32” long) (1) 94450-4 [C]
-
LM2305A-5X-B (38-19/32” long)
(1) 94450-5 [C]
30 Cup Follower (1) 94517 [C]
n
31 Piston Cup (1) 94449 [U]
32 Washer (1) 94516 [C]
33 Ball (1” o.d.) (1) Y16-232 [C]
34 Inner Check Seat (1) 75681 [C]
35 Base - LM2305A-X1-B (1) 96250 [C]
- LM2305A-X2-B (1) 96250-1 [C]
36 Nut (1/4” - 20) (4) 93828 [SS]
37 Ground Screw (#10 - 32 x 1/4”) (1) 93005 [C]
n
38 Gasket (1) 96032 [Co]
39 Tube -
LM2305A-1X-B (7-1/2” long)
(1) 94393-1 [C]
- LM2305A-3X-B (27-23/32” long) (1) 94393-3 [C]
- LM2305A-4X-B (37-15/32” long) (1) 94393-4 [C]
- LM2305A-5X-B (45-3/32” long) (1) 94393-5 [C]
n
40 “O” Ring (1/8” x 1-7/8” o.d.) (1) Y325-223 [B]
41 Ball (1-1/4” o.d.) (1) Y16-240 [C]
42 Ball Stop Pin (3/16” dia. x 1-13/16”) (1) 83009 [C]
43 Foot Valve Seat - LM2305A-X1-B (1) 94398 [C]
- LM2305A-X2-B (1) 94398-1 [C]
44 Bung Ass’y (includes items 45 and 46) (1) 67145-4-B [Z]
45 Thumb Screw (1/4” - 20 x 1-1/2”) (1) Y197-158-C [C]
46 Nut
(1/4” - 20)
(1) Y12-4-C [C]
n
Gadus S2 U1000 Grease Packet (1) 94833
n
Parts in Repair Kit 637226
GENERAL DESCRIPTION
Model LM2305A-X-B series two-ball, double acting pumps are intended
to be used primarily for oil transfer and delivery systems. It is best to use
this pump with low -- medium viscosity fluids. It uses carbon steel and
other materials which make it compatible with most petroleum based lu-
brication products. The two-ball design provides better priming of the
lowerfootvalve. Doubleacting pumpswilldelivermaterialonboth theup
and down stroke.
NOTE: If this pump was purchased separately (not part of a system),
consult your sales representative for compatible dispensing accesso-
ries which will best match the application. All accessories must be able
to withstand the maximum pressure developed by the pump.
MATERIAL CODE
[A] = Aluminum [Co] = Copper [SS] = Stainless Steel
[B] = Nitrile [D] = Acetal [U] = Polyurethane
[Br] = Brass [N] = Neoprene [Z] = Zinc
[C] = Carbon Steel
