Ingersoll-Rand ARO NP828C01-1 User Manual

Pump and cart assembly

background image

E

2003

CCN 20051306

&

(419) 636-4242

D

FAX (419) 633-1674

INGERSOLL-RAND COMPANY

P.O. BOX 151

D

ONE ARO CENTER

D

BRYAN, OHIO 43506Ć0151

NP828C01-1

Pump and Cart Assembly

OPERATOR’S MANUAL

NP828C01-1

RELEASED:

5-2-03

REVISED:
(REV. 01)

INCLUDE MANUALS: Refer to list below.

INCLUDING: SPECIFICATIONS, PUMP DATA, SERVICE KITS

READ THIS MANUAL CAREFULLY BEFORE INSTALLING,

OPERATING OR SERVICING THIS EQUIPMENT.

It is the responsibility of the employer to place this information in the hands of the operator. Keep for future reference.

8” AIR MOTOR
28:1 RATIO
6” STROKE

DO NOT EXCEED MAXIMUM WORKING PRESSURE OF 3360 P.S.I. (231.7 BAR) AT 120

P.S.I. 8.3 BAR) AIR INLET PRESSURE.

SERVICE KITS

Use only genuine AROR replacement parts to assure compatible

pressure rating and longest service life.

29960 for repair of 27354Ć000 regulator.

66614 for repair of 66523ĆB air motor.

104020 for repair of 25351Ć010 filter.

104023 for repair of 26351Ć010 lubricator.

637098ĆR43 for repair of 66475ĆR4D lower pump section.

637103 for repair of 651533 spray gun.

OPERATING AND SAFETY PRECAUTIONS

WARNING

READ THE GENERAL INFORMATION MANUAL

INCLUDED FOR OPERATING AND SAFETY PRECAUTIONS

AND OTHER IMPORTANT INFORMATION.

GENERAL DESCRIPTION

The ARO model NP828C01Ć1 pump and cart assembly is designed to

provide portability to a pump that is primarily used for airless spray apĆ

plications. Materials of light Ć medium viscosity are best suited for the

unit.

IMPORTANT

This is one of the fourteen documents which support the various compoĆ

nents of the system. Replacement copies are available upon request.

= NP828C01Ć1 Model Operator's Manual

(pn 97999Ć1024)

- 650865ĆXĆB TwoĆBall Pump

(pn 97999Ć878)

- SĆ636 General Information Ć Pumping Systems

(pn 97999Ć636)

- 66475āĆX Lower Pump End

(pn 97999Ć111)

- 66523ĆB Air Motor

(pn 97999Ć868)

- 66554ĆX Heavy Duty Cart

(pn 97999Ć574)

- 66559 Check Valve

(pn 97999Ć315)

- 65030ĆXĆB Filter and Swivel Assembly

(pn 97999Ć587)

- 651533ĆX Spray Gun

(pn 97999Ć83)

- 651418ĆXĆB Material Filter

(pn 97999Ć8)

- 651728ĆX FĆRĆL Accessory Kit

(pn 97999Ć419)

- WARNING Ć High Pressure Equipment

(pn 97999Ć540)

- 253XXĆX Heavy Duty Filter Ć Regulator Ć Lubricator

(pn 103942)

- SĆ632 General Information Ć Industrial Piston Pumps

(pn 97999Ć624)

INSTALLATION

The unit comes completely assembled.

PUMP DATA

NP828C01Ć1 Pump and Cart Assembly

Figure 1

OPERATION

See 650865ĆXĆB pump manual installation for flushing instructions. AfĆ

ter the pump has been flushed with a compatible solvent and is ready for

operation:

1. Place 66728 suction hose into material.

2. Connect air line to 651728Ć1 Filter Ć Regulator Ć Lubricator.

3. Turn knob on air regulator clockwise to start pump.

4. Allow pump to cycle slowly and prime with material. This will bleed

trapped air from the system.
