Page 23: Stabilizer bracket (4 screws included)

Installation and User Manual
1.5.7
Transformer Module
This module provides isolated 120/208/240Vac output.
Figure 1-12: Typical Transformer Module contents and connections.
1 — 11
86-86000-00 A01
Introduction
www
.mge
ups.c
om
E X
R T
Tra
nsforme
r
EX RT Transformer Module Contents
Tower Stand Expanders
Transformer User Manual
BATTERY MODULE
EXB RT
POWER MODULE
EX 5/7/11 RT
TRANSFORMER
MODULE EX RT
AC NORMAL
INPUT
STEP-DOWN
TRANSFORMER
OUTPUT TO LOAD
Stabilizer Bracket
(4 screws included)
