Vertical Line Widths
The following table shows the vertical line widths.
Line Width
Line
Number
Appearance
Inches
MM
1
.003
.076
2
.008
.177
3
.011
.279
4
.015
.381
5
.019
.457
6
.023
.558
7
.027
.660
8
.030
.762
9
.034
.863
10
.038
.939
11
.042
1.041
12
.046
1.143
13
.049
1.244
14
.053
1.346
15
.057
1.422
