Monarch Instrument 6032 - Manual

• Programmable Printer
• Integrated Printer with Optional
Scanner
• Portable Printer
• Thermal Direct
• Custom Formatted
• Prints Receipts, Tags and Labels
• Supports TrueType® and
Bitmapped Fonts
M M o o n n a a r r c c h h
® ® P P a a t t h h f f i i n n d d e e r r
® ® U U l l t t r r a a
® ®
S S i i l l v v e e r r 6 6 0 0 3 3 2 2 ™ ™ P P r r i i n n t t e e r r
STANDARD FEATURES
Dimensions:
Height – 6.5" (165 mm)
Width – 7.75" (197 mm)
Depth – 3.25" (83 mm)
Weight – 1.973 lbs. (.90 kg)
Shipping Wt. – 4.09 lbs. (1.86 kg)
Printing Method:
Thermal Direct
Printhead:
2.0" (50.8 mm)
203 dots/inch (8 dots/mm)
Keypad/Display:
25 keys (inc. on/off) alpha/numeric supported
2-line 15 character with backlight display
feature
Memory:
1 MB RAM, 2 MB Flash
Bar Code Types:
UPCA +2/+5, UPCE +2/+5, EAN8 +2/+5,
EAN13 +2/+5, Interleaved 2 of 5, Codabar,
Code 128, Code 39, MSI
Standard Fonts:
Standard, Reduced, Bold, OCRA-like, EFF
Swiss Bold*, HR1, and HR2 (HR1 and HR2 are
only for numeric data.)
∗ Also available as a scalable font. The printer supports
Bitmapped, TrueType® and International fonts.
Font Magnification:
1x to 7x for Bitmapped fonts
4 to 250 pt. for scalable/TrueType fonts
Printer Warranty:
One (1) year parts and labor (ship-in).
Full written warranty statement is available
on request.
Printhead Warranty:
Six (6) months, or one million inches
(1,000,000"), whichever occurs first.
Battery and Cable Warranty:
Three (3) Months pro-rated from date of
shipment. Physical damage to the batteries
or cables will not be covered by the limited
warranty
