Monarch Instrument MWS 9878 - Manual

• Mobile Work Station (MWS)
for Tabletop Printers and
Small to Medium Laser
Printers
• Customizable
• Power Management
System
• Battery Status Panel
Monarch
®
9878
™
MWS
™
(Laser Sign Printer)
Product Specification
STANDARD FEATURES
Dimensions:
Height – 37" (940 mm)
Width – 20.5" (521 mm)
Length – 39.5" (1003 mm)
Wheelbase – 18" (457 mm)
Weight - 200 lbs. (91 kg)
(2 batteries, 1000W AC Inverter, charger, curved
handle, laminated wood top, two fixed locking and two
swivel casters)
Laminated wood top work surface 20"W x 26"L (508
mm x 660 mm)
Lower Shelf – 15"W x 25"L (381 mm x 635 mm)
Battery Power:
Laser Printer Model – 24 VDC,
(2) 55 AH Deep cycle batteries, sealed lead-acid, non-
venting, no transportation restrictions
Cycle Use:
100% depth of discharge, approx. 250 cycles
50% depth of discharge, approx. 550 cycles
30% depth of discharge, approx. 1200 cycles
Cycle life is approximate and many factors affect MWS
battery performance
Battery Status Panel:
Lights - Red, Yellow, and Green
Tone - Battery Low Alert
Charger Input:
115VAC +/-10% (60Hz), 230VAC (50Hz)
IEC Connection
Charger Output:
5 hours "typical" charge time
Reverse polarity and short circuit-proof
Temperature compensated
Smart charging
10-amp peak charging current
6 to 10 hour battery duration in "typical" conditions
Product Warranty:
One (1) year Parts and Labor
Two (2) months On-Site, Ten (10) months Depot
Return
ENVIRONMENT RANGES
Operating Temperature:
40° to 104° F (5° to 40° C)
Storage:
40° to 140° F (5° to 60° C)
Humidity/Operating and Storage:
5% to 90% non-condensing
Electrostatic Discharge and Air Quality:
Some problems with electronic equipment may occur in environments prone to static discharge or extreme dust
conditions. Paxar suggests that you take precautions to minimize these problems.
