51D0528 9
LX Series Direct Vent Gas Fireplace cLeARANceS
cLeARANceS to coMBuStIBLeS
Follow these instructions carefully to ensure safe installation. Failure to
follow instructions exactly can create a fire hazard.
the appliance cannot be installed on a carpet, tile or other combustible
material other than wood flooring. If installed on carpet or vinyl flooring, the
appliance shall be installed on a metal, wood or noncombustible material
panel extending full width and depth of the appliance.
W
ARNING
12” (305 mm)
Max. Depth
9” (229 mm)
Minimum
LX32 - 39” (991 mm)
LX36 - 43” (1092 mm
)
LX32 - 30” (762 mm)
LX36 - 34” (864 mm)
6”
(152 mm)
12” (305 mm)
Minimum
466M”
(1187 mm)
446M”
(1137 mm)
FP2711
combustible clearances
Side Wall
Ceiling
Combustible
Mantel
Noncombus-
tible Facing
FP2711
Figure 5 -
Clearances to Combustible
Materials
MANteL cLeARANceS
Note: the combustible area above the facing must
not protrude more than 3/4" from the facing. If it does,
it is considered a mantel and must meet the mantel
requirements listed in this manual.
heARth RequIReMeNtS
The fireplace must be installed on a non-combustible hearth
extending a minimum of 12" from the fireplace opening
(local codes may require a larger hearth). The hearth must
also extend to both sides of the face (see the table above
for the exact width of the face).
