LX Series Direct Vent Gas Fireplace
RepLAceMeNt pARtS
LX32DV
LX36DV
Ref. Description
qty.
Natural
propane
Natural
propane
1. Rear Log
1
51D0402
51D0402
51D0002
51D0002
2. Bottom Left Log
1
51D0403
51D0403
51D0003
51D0003
3. Bottm Right Log
1
51D0404
51D0404
51D0004
51D0004
4. Left Top Log
1
51D0405
51D0405
51D0005
51D0005
5. Right Top Log
1
51D0406
51D0406
51D0006
51D0006
6. Left Mid Log
1
51D0407
51D0407
51D0007
51D0007
7. Right Mid Log
1
51D0408
51D0408
51D0008
51D0008
8. Center Log
1
51D0409
51D0409
51D0009
51D0009
9. Blower UPPCO
1
26D0748
26D0748
26D0748
26D0748
10. Speed Control
1
26D0746
26D0746
26D0746
26D0746
11. Thermostat Sensor
1
26D2870
26D2870
26D2870
26D2870
12. Junction Box
1
26D2128K
26D2128K
26D2128K
26D2128K
13. Glass Assembly
1
51D0417K
51D0417K
51D0417K
51D0417K
14. Firebrick Center
1
51D0411
51D0411
51D0012
51D0012
15. Firebrick Left
1
51D0013
51D0013
51D0013
51D0013
16. Firebrick Right
1
51D0192
51D0192
51D0192
51D0192
17. Wire Harness Male
1
44D0501
44D0501
44D0501
44D0501
18. Wire Harness Female
1
44D0500
44D0500
44D0500
44D0500
19. SIT 820 Nova Valve
1
37D0117
37D0118
37D0117
37D0118
20. Knob Extension Hi/Lo
1
43D0095
43D0095
43D0095
43D0095
21. Knob Extension On/Off
1
43D0094
43D0094
43D0094
43D0094
22. Pilot Assembly
1
37D0018
37D0019
37D0018
37D0019
23. Front Burner Assembly
1
51D0037K
51D0037K
51D0037K
51D0037K
24. Rear Burner Assembly
1
51D0431K
51D0431K
51D0041K
51D0041K
25. Injector Front Burner
1
51D0425K
51D0423K
51D0032K
51D0030K
26. Injector Rear Burner
1
51D0425K
51D0422K
51D0031K
51D0029K
27. Flexhose w/Shutoff Valve
1
23D6046
23D6046
23D6046
23D6046
28. Rocker Switch
1
41D0048
41D0048
41D0048
41D0048
29. Ignitor Battery Assembly
1
45D0242K
45D0242K
45D0242K
45D0242K
Accessories (not shown)
Thermostatic Remote Control
RCT
Remote Control On/Off
RCM
Wall Switch Kit
MVWS
Wall Thermostat Kit
MVWTS
Deflector Shield
37D0115K
Fuel conversion Kits
Natural Gas to Lp
LX32DVNV
Kit #LX32CKP LX32HAKP*
LX36DVNV
Kit #LX36CKP LX32HAKP*
Lp to Natural Gas
LX32DVPV
Kit #LX32CKN LX32HAKN*
LX36DVPV
Kit #LX36CKN LX32HAKN*
*High Altitude Conversion Kits
