Minolta Magicolor 2200 - Manual (Page 28)

Replacing the Fuser Unit and Transfer Roller Kit 20
10
Press down on the fuser
unit release levers
and
rotate them .
This secures the fuser
unit.
Attention
If the fuser unit release levers are not set correctly, the fuser oil roller cannot be
installed. Set the fuser unit release levers to the fixed position.
11
Reinstall the fuser oil
roller (removed in
step 4).
1
1
2
2
2
2
1
1
