Maxtor 4-Channel DVR (Digital Video Recorder) User Manual
Page 56
56
- DVR Speaker Enable
This option enables/disables the speaker of the DVR (Not the audio output of the
client). If you enabled the DVR audio recoding and the speaker is enabled, you
would be able to hear audio sound from the DVR.
- Input Channels
Select the camera that should be on for monitoring. To make all of four cameras to
activate, all channels should be “ON” mode.
If you want to turn off some of the cameras, click “ON” button. Then it will be turned
off.
- Record Channels
Select channels(cameras), which should operate for recording. If you turn off some
of channels, the selected channels(cameras) won’t record during recording session.
- DVR Time
Throughout remote connection, you can change date/time/hour/minute/sec setting on
DVR.
- Record Schedule
12am-1am
No Schedule
Sensor
Recording
For recording
11pm-12am
You can set recording schedule for 24-hour period. When you set the record schedule
