26
SENSOR/ MOTION SETUP
SENSOR/ MOTION RECORD TIME 10
ALARM OUT TIME 00
SENSOR TYPE MOTION
>CH-1 NOT INSTALLED
CH-2 NOT INSTALLED
CH-3 NOT INSTALLED
CH-4 NOT INSTALLED
PRESS (UP, DOWN) , THEN (SELECT)
PRESS (MENU) TO EXIT
In NORMAL-CLOSE mode, if an intruder cuts the cable line that connects the sensor to the DVR, sensor
recording starts automatically. In NORMAL-OPEN mode, if an intruder cuts the cable line that connects
the sensor to the DVR, the sensor recording will not start at all.
MOTION SETUP
There are 5 different modes for sensor activated recording:
1. OFF: No motion direction is connected to the DVR unit.
2. Level 1~4: Level 4 is the most sensitive.
NETWORK SETUP
NETWORK SETUP is available for this DVR.
If you plan to connect your DVR unit to a network, navigate to NETWORK SETUP.
MAIN MENU
CAMERA SELECT 1234
RECORD SELECT 1234
RECORD MODE EACH
RECORD FRAMERATE 30
VIDEO QUALITY NORMAL
RECORD SCHEDULE
SUB MENU
HARD DRIVE SETUP
SENSOR / MOTION SETUP
> NETWORK SETUP
Then, press the select button to display the following menu:
NETWORK SETUP
> ACCEPT CLIENT [YES]
MAC ADDRESS 00.22.24.23.25.26
IP ADDRESS 192.168.001.090
SUBNET MASK 255.255.255.000
GATEWAY 192.168.991.245
PRESS (UP, DOWN) , THEN (SELECT)
PRESS (MENU) TO EXIT
