35
Connection Supporting 1 Client FUNCTION:
-Live Monitoring
-HDD Searching
-Setup Available
ALARM
Sensor Input
4 Port / NC or NO Non-isolated TTL input
Ground Common
Alarm Output 1Port / NO Isolated Relay Output
* Motion Detection Available for each camera Multi Detection
Level
CONNECTOR
Video Input
4 Ports (BNC)
Loop Through Output 4 Ports (BNC)
Audio Input (mono) RCA 1 Port (White)
Audio Output (mono) Line Output, RCA Jack (Red)
Main TV Output 2 Ports (BNC)
Sensor Input 8 pins Terminal Block (4 pins Ground
Terminal)
Alarm Output 2 pins Terminal Block
Ethernet RJ-45, 10Mbps / 100Mbps
ELECTRICAL
Power Source
DC12V, 5A
Power Consumption Appx. 30Watt
ENVIRONMENTAL
Operating Temp.
+5 ~ +40°C
Storage Temp. +5 ~ +60 °C
Humidity 30 ~ 80 %RH (non-condensing)
PHYSICAL
Dimension
335 (W) x 65(H) x 250 (D) mm
Weight Appx. 2kg
OTHERS
OSD Language
Multi-language (English, Japanese,
Chinese, Korean, German, Portuguese,
Spanish, Danish, French)
Remote Control Available
