30
SEARCH TIME
> HARD DRIVE: MASTER
03/05/21 06:59:59 – 03/05/21 06:59:59
> 01 TIME 2004/05/21 01:15:20
02 TIME 2004/05/21 00:25:33
03 TIME 2004/05/20 11:35:55
04 TIME 2004/05/20 10:48:12
05 SENSOR 2004/05/20 09:57:55
(UP, DOWN) MOVE (PLAY) PLAY
(MENU) EXIT (FF) SELECT EVENT OR TIME
VIEW CONTROL DURING PLAYBACK
If you have set the RECORD MODE to EACH (see page 19), you can use the select button on the
DVR front panel to select the camera that you want to view in full screen during playback.
CH1- If you press the select button once, you can see camera1 in full
screen.
CH2- If you press the select button twice, you can see camera2 in full
screen.
CH3- If you press the select button three times, you can see camera3
in full screen.
CH4- If you press the select button four times, you can see camera4 in
full screen.
ALL- If you press the select button five times, you can see all cameras
in full screen.
Quad screen: Images from all 4 cameras are displayed at the same time in 4 separate
sections on a single screen.
Note: You cannot view individual cameras in FULL SCREEN display while in QUAD mode. You can only
view a quad screen when the RECORD MODE is set to QUAD (see page 19).
