G E T T I N G S TA R T E D
1
The Monarch
®
9403
printer prints text, graphics, and bar codes
on thermal transfer (ribbon) or thermal direct supplies. The 9403
printer prints labels continuously (in one strip).
This chapter includes information about
◆
unpacking the printer.
◆
connecting the power cable.
◆
connecting the communications cable.
◆
using the printer’s control panel.
S t a n d a r d F e a t u r e s
The following features are standard on the 9403 printer:
◆
203 dots per inch (DPI) printhead
◆
2-inch by 6-inch print image
◆
21-key keypad
◆
2 inches per second maximum print speed
◆
baud rate up to 19200
◆
formats, graphics, and check digits saved in Flash memory when printer
is turned off (version 2.0 or greater)
Getting Started 1-1
