S u p p l y L o a d i n g D i a g r a m
The illustration below shows the correct routing for supplies and
ribbon.
Guide the ribbon around the ribbon guide
rollers when loading.
Ribbon
Guide
Rollers
Ribbon
Supply
Guide
Roller
Supply
Roll
2-2 Loading Supplies
