The test label displays
◆ printer model number
◆ software version number
◆ number of inches printed to date
◆ user COM port settings
◆ a test pattern.
This information will help Technical Support diagnose the
problem. Refer to the Packet Reference Manual for more
information about the test label.
C h e c k i n g S e n s o r M a r k Q u a l i t y
The printer continuously stores data from the most recent 16
supplies printed. This checks the quality of the sensor marks on
the supply.
Print a batch of supplies or test labels.
To check the sensor mark quality:
From the Diagnostics Menu, press L or R until you see
DIAGNOSTICS
User Diag
1. Press E. Press L or R until you see
USER DIAG
Supply Quality r
2. Press E. If you have not printed any labels, you will see a
message saying "No data."
Diagnostics 10-5
