4 Loading Paper
4-6 CF2002/CF3102
4.4 Loading Paper
Loading Paper Into the 1st Drawer
1 Pull out the paper drawer for the
1st drawer.
2 Press down on the paper-lifting
plate until it locks into place.
? Has the paper take-up roller
been touched?
➜ Be careful not to touch the
surface of the paper take-up
roller with your hands. If the
roller has been touched, wipe it
with a dry cloth.
3 Slide the lateral guides to fit the size
of paper to be loaded.
❍ For paper of a non-standard
size, first load the paper, and
then adjust the lateral guides to
the size of the loaded paper.
4 For “A3Wide” paper, adjust the
trailing-edge guides as shown in the
illustration.
Paper take-up roller
