Page 127
7
Replacing Parts and Supplies
7-8
CF2002/CF3102
To replace the staple cartridge for FN-8
1
Open the front door of the finisher.
2
Turn misfeed-clearing dial
clockwise until the removal indicator
is completely blue.
❍
If the dial is turned too far, turn it
counterclockwise to adjust it.
3
Slowly pull out the stapler unit as far
as possible.
4
Turn dial
clockwise until the
staple cartridge moves to a position
from where it can be removed.
❍
If the dial is turned too far, turn it
counterclockwise to adjust it.
CF2002.book Page 8 Friday, June 13, 2003 9:29 AM
