DS5001FP
4 of 26
PIN DESCRIPTION
80-PIN
MQFP
44-PIN
MQFP
SIGNAL
DESCRIPTION
11, 9, 7,
5, 1, 79,
77, 75
31
(P0.5)
P0.0–P0.7
General-Purpose I/O Port 0. This port is open-drain and cannot drive a logic 1. It requires
external pullups. Port 0 is also the multiplexed expanded address/data bus. When used in
this mode, it does not require pullups.
15, 17,
19, 21,
25, 27,
29, 31
44
(P1.3)
P1.0–P1.7
General-Purpose I/O Port 1
49, 50,
51, 56,
58, 60,
64, 66
N/A
P2.0–P2.7
General-Purpose I/O Port 2. Also serves as the MSB of the address in expanded memory
accesses, and as pins of the RPC mode when used.
36
8
P3.0 RXD
General-Purpose I/O Port Pin 3.0. Also serves as the receive signal for the on board
UART. This pin should not be connected directly to a PC COM port.
38
10
P3.1 TXD
General-Purpose I/O Port Pin 3.1. Also serves as the transmit signal for the on board
UART. This pin should not be connected directly to a PC COM port.
39
N/A
P3.2
INT0
General-Purpose I/O Port Pin 3.2. Also serves as the active-low external interrupt 0.
40
11
P3.3
INT1
General-Purpose I/O Port Pin 3.3. Also serves as the active-low external interrupt 1.
41
N/A
P3.4 T0
General-Purpose I/O Port Pin 3.4. Also serves as the timer 0 input.
44
12
P3.5 T1
General-Purpose I/O Port Pin 3.5. Also serves as the timer 1 input.
45
13
P3.6
WR
General-Purpose I/O Port Pin. Also serves as the write strobe for expanded bus
operation.
46
N/A
P3.7
RD
General-Purpose I/O Port Pin. Also serves as the read strobe for expanded bus operation.
68
25
PSEN
Program Store Enable. This active-low signal is used to enable an external program
memory when using the expanded bus. It is normally an output and should be unconnected
if not used.
PSEN
also is used to invoke the bootstrap loader. At this time,
PSEN
is pulled
down externally. This should only be done once the DS5001FP is already in a reset state.
The device that pulls down should be open drain since it must not interfere with
PSEN
under normal operation.
34
6
RST
Active-High Reset Input. A logic 1 applied to this pin will activate a reset state. This pin
is pulled down internally so this pin can be left unconnected if not used. An RC power-on
reset circuit is not needed and is not recommended.
70
27
ALE
Address Latch Enable. Used to demultiplex the multiplexed expanded address/data bus
on port 0. This pin is normally connected to the clock input on a ’373 type transparent
latch.
47, 48
14, 15
XTAL2,
XTAL1
XTAL2, XTAL1. Used to connect an external crystal to the internal oscillator. XTAL1 is
the input to an inverting amplifier and XTAL2 is the output.
52
16
GND
Logic Ground
13
39
VCC
V
CC
- +5V
12
38
VCCO
V
CCO
- V
CC
Output. This is switched between V
CC
and V
LI
by internal circuits based on the
level of V
CC
. When power is above the lithium input, power will be drawn from V
CC
. The
lithium cell remains isolated from a load. When V
CC
is below V
LI
, the V
CCO
switches to the
V
LI
source. V
CCO
should be connected to the V
CC
pin of an SRAM.
54
17
VLI
Lithium Voltage Input. Connect to a lithium cell greater than V
LIMIN
and no greater than
V
LImax
as shown in the electrical specifications. Nominal value is +3V.
53, 16,
8, 18,
80, 76,
4, 6, 20,
24, 26,
28, 30,
41, 36,
42, 32,
30, 34,
35, 43,
1, 2, 3,
4, 5, 7,
BA14–0
Byte-Wide Address-Bus Bits 14–0. This bus is combined with the nonmultiplexed data
bus (BD7–0) to access NV SRAM. Decoding is performed using
CE1
through
CE4
.
Therefore, BA15 is not actually needed. Read/write access is controlled by R/
W
. BA14–0
connect directly to an 8k, 32k, or 128k SRAM. If an 8k RAM is used, BA13 and BA14 are
unconnected. If a 128k SRAM is used, the micro converts
CE2
and
CE3
to serve as A16
