DS5001FP
21 of 26
RPC AC CHARACTERISTICS, DBB WRITE (T
A
= 0°C to +70°C; V
CC
= 5V ±10%)
# PARAMETER SYMBOL MIN MAX UNITS
60
CS , A
0
Setup to WR
t
AW
0 ns
61A
CS , Hold After WR
t
WA
0 ns
61B A
0
, Hold After WR
t
WA
20 ns
62
WR Pulse Width t
WW
160 ns
63
Data Setup to WR
t
DW
130 ns
64 Data Hold After WR
t
WD
20 ns
AC CHARACTERISTICS, DMA (T
A
= 0°C to +70°C; V
CC
= 5V ±10%)
# PARAMETER SYMBOL MIN MAX UNITS
65
DACK to WR or RD
t
ACC
0 ns
66
RD or WR to DACK
t
CAC
0 ns
67
DACK to Data Valid t
ACD
0 130 ns
68
RD or WR to DRQ Cleared
t
CRQ
110 ns
AC CHARACTERISTICS, PROG (T
A
= 0°C to +70°C; V
CC
= 5V ±10%)
# PARAMETER SYMBOL MIN MAX UNITS
69
PROG Low to Active t
PRA
48 CLKS
70
PROG High to Inactive
t
PRI
48 CLKS
