DC CHARACTERISTICS (continued) (T
A
= 0°C to +70°C; V
CC
= 5V ±10%)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Input Leakage Current
0.45 < V
IN
< V
CC
(Port 0, MSEL)
I
IL
+10 µA
RST Pulldown Resistor
(0°C to +70°C)
R
RE
40 150 k W
RST Pulldown Resistor
(-40°C to +85°C)
R
RE
30 180 k W 10
VRST Pullup Resistor R
VR
4.7 k W
PROG Pullup Resistor R
PR
40 k W
Power-Fail Warning Voltage
(0°C to +70°C)
V
PFW
4.25 4.37 4.50 V 1
Power-Fail Warning Voltage
(-40°C to +85°C)
V
PFW
4.1 4.37 4.6 V 1, 10
Minimum Operating Voltage
(0°C to +70°C)
V
CCMIN
4.00 4.12 4.25 V 1
Minimum Operating Voltage
(-40°C to +85°C)
V
CCMIN
3.85 4.09 4.25 V 1, 10
Lithium Supply Voltage V
LI
2.5 4.0 V 1
Operating Current at 16MHz I
CC
36 mA 2
Idle Mode Current at 12MHz
(0°C to +70°C)
I
IDLE
7.0 mA 3
Idle Mode Current at 12MHz
(-40°C to +85°C)
I
IDLE
8.0 mA 3, 10
Stop Mode Current I
STOP
80 µA 4
Pin Capacitance C
IN
10 pF 5
Output Supply Voltage (V
CCO
)
V
CCO1
V
CC
-0.45
V 1, 2
Output Supply Battery-Backed Mode
(V
CCO
, CE 1-4, PE 1-2)
(0°C to +70°C)
V
CCO2
V
LI
-0.65
V 1, 8
Output Supply Battery-Backed Mode
(V
CCO
, CE 1-4, PE 1-2)
(-40°C to +85°C)
V
CCO2
V
LI
-0.9
V 1, 8, 10
Output Supply Current
at V
CCO
= V
CC
- 0.45V
I
CCO1
75 mA 6
Lithium-Backed Quiescent Current
(0°C to +70°C)
I
LI
5 75 nA 7
Lithium-Backed Quiescent Current
(-40°C to +85°C)
I
LI
75 500 nA 7
Reset Trip Point in Stop Mode
With BAT = 3.0V (0°C to +70°C)
With BAT = 3.0V (-40°C to +85°C)
With BAT = 3.0V (0°C to +70°C)
4.0
3.85
4.4
4.25
4.25
4.65 1
1, 10
1
