Macsense Connectivity MPC-200 - Manual (Page 31)

NDIS Driver For Windows For Workgroups 3.11
INSTALLATION PROCEDURE
1. Execute INSTWFW.BAT file and add two command lines bellow to your. AUTOEX-
EC.BAT file
PATH C:\NWCLIENT;%PATH%
C:\NWCLIENT\STARTCB.BAT
Note: If these two command lines have already existed in your autoexec.bat file, you can
skip this step.
2. Run Windows by typing WIN from the DOS prompt.
3. Click the Network icon in the Main Program Group.
4. Click the Network Setup icon from the Network window.
5. Select Drivers item from the Network Setup dialog box.
6. Select Add Adapters item in the Option dialog box.
7. Select Unlisted or Updated Network Adapter when the Install driver field
appears.
8. Type destination drive and path name in your PC. Make sure the full path of the
directory (i.e. A:\WFW311) is given.
9. Insert the Driver Diskette in your floppy drive and press to start the installa-
tion process.
10. When the Macsense Fast Ethernet CardBus Card dialog box appear, select the
options step by step.
11. Follow the steps shown on screen to complete the process.
12. Restart your computer.
NDIS Driver For LAN Manager
Installation Procedure
1. Copy all the files and directories in MSLANMAN.DOS from Installation Disk by
using XCOPY command.
2. Type lmsetup In Lan Manager Directory. Press Enter .
3. Select Network Drivers... in Configuration. Press Enter .
4. Select ,press Ente r. Network Adapter Driver appears.
5. Select , press Ente r.
30
Client Driver Installation
