IC 24
C1DB00001373
IC, USB-ATA CHIP
1
IC 25, 64, 68
C0JBAZ002422
IC, FET SWITCH
3
IC 26, 37, 38
C0EBE0000460
IC
3
IC 27, 29
C0JBAR000515
IC, Q-SWITCH
2
IC 28
C0DBZYY00016
IC
1
IC 30
C1CB00002449
IC, AUDIO CODEC
1
IC 31
C0CBCBC00181
IC
1
IC 32
C1AB00002507
IC, AUDIO POWER AMPLIFIER
1
IC 33
C1CB00002268
IC, SECURITY CHIP
1
IC 34
C3FBLY000024
IC, SPI FLASH MEMORY
1
IC 36
C2CBJA000003
IC, MICON
1
IC 42
C0JBAB000832
IC, LOGIC
1
IC 43, 44, 54, 55, 61, 614
C0JBAA000362
IC, LOGIC
6
IC 45, 51
C0JBAE000321
IC, LOGIC
2
IC 46, 47, 48, 49,
C0JBAA000345
IC, LOGIC
4
IC 50
C1CB00002295
IC
1
IC 52, 603, 604
C0JBAB000621
IC, LOGIC
3
IC 53, 601
C0ABBA000093
IC, OP AMP
2
IC 58
C0DBZYY00019
IC, POWER MANAGEMENT SWITCH
1
IC 63
C0JBAB000686
LOGIC IC
1
IC 600, 602, 609
C0DBALH00003
IC
3
IC 605
C0DBAYY00155
IC, DC/DC
1
IC 606
C0DBEFH00002
IC, REGULATOR
1
IC 607
C0DBDJH00009
IC, LINER
1
IC 608
C0ABZA000047
IC, AMP
1
IC 610
C0EBE0000333
IC
1
IC 615
C0DBAZZ00098
IC
1
IC 617
C0EBE0000591
IC, RESET
1
KJ 1, 2
K2HC1YYB0027
JACK
2
L 1, 3
G1C1R0MA0076
INDUCTOR
2
L 2
G1C91NM00001
INDUCTOR
1
L 4
J0JJC0000021
INDUCTOR
1
L 5, 7, 11, 15, 26
J0JHC0000074
INDUCTOR
5
L 9, 10, 13, 14, 27, 28, 29,
30, 31, 32, 33
J0JCC0000186
INDUCTOR
11
L 17, 18, 19
J0JBC0000072
INDUCTOR, FILTER
3
L 20
G1C1R0Z00002
INDUCTOR
1
L 21, 22, 23, 24
J0ZZB0000080
IDUCTOR, COMMON MODE FILTER
4
L 25
DDB5Z024E-L
INDUCTOR
1
L 34, 35, 36, 37
DDB5Z024C-L
IDUCTOR, FERRITE PARTS
4
L 38, 39, 40, 41, 42, 43
DDB5Z021C-Y
INDUCTOR
6
L 44
J0MAB0000116
INDUCTOR
1
L 600
J0JKC0000007
INDUCTOR
1
L 601, 606, 607
G1C4R7MA0022
INDUCTOR
3
L 602
G1C100MA0022
INDUCTOR
1
L 603
G1CR56ZA0140
COIL
1
L 604
G1C2R8MA0022
INDUCTOR
1
L 605
G1C220MA0077
INDUCTOR
1
L 608
G1A160H00001
INDUCTOR
1
L 609
G1C4R7MA0273
COIL
1
PA 1, 2, 3
S D4FB1R100009
SWITCH
3
Q 1, 24
B1GDCFNN0031
TRANSISTOR
2
Q 2, 3, 4, 25, 34, 604, 606,
619, 645, 646, 651, 652,
653, 657, 658,
B1GBCFJN0037
TRANSISTOR
15
Q 5, 622, 627
B1CHRC000009
FET
3
Q 6, 7, 27, 654, 662
B1CFGD000023
TRANSISTOR
5
Q 10, 36, 38, 616, 621,
628, 631, 632, 634, 635,
XP0421300L
TRANSISTOR
11
Q 11, 30, 626, 630, 633
B1DHDC000028
TRANSISTOR
5
Q 19
B1GDCFJJ0050
TRANSISTOR
1
Q 20, 21
XP0411300L
TRANSISTOR
2
