CN 4
K1MN50BA0153
CONNECTOR
1
CN 6
K1MN24BA0070
CONNECTOR
1
CN 7
K1FY150BA007
CONNECTOR
1
CN 8
K1MN60B00008
CONNECTOR
1
CN 9
K1KA05BA0181
CONNECTOR
1
CN 10
K1KY30BA0062
CONNECTOR
1
CN 11
K1FB315BA003
CONNECTOR
1
CN 12
K1NA09E00076
CONNECTOR
1
CN 13
K1NA68E00096
CONNECTOR
1
CN 14
K1KA08BA0181
CONNECTOR
1
CN 15
K1KA04BA0014
CONNECTOR
1
CN 17
K1KY12A00004
CONNECTOR
1
CN 18
K1MY52BA0190
CONNECTOR
1
CN 20
K1MN12BA0070
CONNECTOR
1
CN 21
K1MY10BA0105
CONNECTOR
1
CN 23
K1KA12BA0181
CONNECTOR
1
CN 24
K1MY16BA0097
CONNECTOR
1
CN 25
K1MY10BA0102
CONNECTOR
1
CN 600
K1KA10B00233
CONNECTOR
1
CN 601
K1KA02B00292
CONNECTOR
1
D 1, 2, 3, 10
MA2J72900L
DIODE
4
D 4
MA3J741E0L
DIODE
1
D 5, 6
B0KB00000044
DIODE
2
D 7, 8, 9, 601, 602, 604
B0ADDH000004
DIODE
6
D 11, 600, 603
B0JCPD000023
DIODE
3
D 12, 619, 621
MA2S111-TX
DIODE
3
D 13,
B3ABB0000196
DIODE
1
D 14
B3AKB0000008
DIODE
1
D 15, 20
B3ACB0000020
DIODE
2
D 16, 17, 18, 19
B3ABB0000164
DIODE
4
D 605
MAZ81200ML
DIODE
1
D 606
MAZ81800ML
DIODE
1
D 607, 622
MA3S132E0L
DIODE
2
D 608
B0JCQD000001
DIODE
1
D 609, 611, 624, 626, 627,
629, 630, 633
B0JCMD000010
DIODE
8
D 610, 625, 628
B0JDAE000004
DIODE
3
D 612, 613, 614, 615, 617,
618
MAZ80510ML
DIODE
6
D 616
MAZ80620ML
DIODE
1
D 620
B2ABAM000002
DIODE
1
D 623, 632, 640
DEDRB081L20
DIODE
3
D 634
MAZ80750ML
ZENER DIODE
1
F 1, 2
S K5H2021A0003
FUSE, 2A
2
F 4
S K5H402Z00003
FUSE, 4A, 32V
1
F 6
S K5H202Z00005
FUSE, 2A, 32V
1
F 600
S K5H802300002
FUSE, 8A
1
IC 1
C2GBC0000304
CPU
1
IC 2
C1CB00002432
IC, CHIP SET
1
IC 3
C1DB00001541
IC, CHIPSET
1
IC 4
C0DBZYY00017
IC
1
IC 5, 6, 7, 8, 9, 10, 11, 12
C3ABSG000030
IC, SDRAM
8
IC 13
C0JBZZ000388
IC, CLOCK GENERATOR
1
IC 15
C0CBCAC00183
IC, REGULATOR
1
IC 16
C0CBCBG00008
IC, REGULATOR
1
IC 17
C1DB00001182
IC, LAN CONTROLLER
1
IC 18
C3EBCG000100
IC, EEPROM
1
IC 19
C0CBCBC00137
IC, REGULATOR
1
IC 20
C1CB00002540
IC, TEMPERATURE CENSOR IC
1
IC 21, 22, 69
C0DBZYY00026
IC, USB POWER SW
3
IC 23
C3EBEC000061
IC, EEPROM
1
