Appendix E: Diamond Shield Instructions
The instructions below will lead you through the
Diamond Shield installation process.
Included in the Diamond Shield package are the
following items:
For models WS-65711, WS-65712 and
WS-73711 only.
(1) Diamond Shield™
(2) molding clips
1. Carefully remove the Diamond Shield™ from
the protective packaging. Wipe off any dust with a
lint-free cloth. Do not use any cleaners on the anti-
glare Diamond Shield™.
2. Begin by inserting the shield, sliding it into the
channels, starting at the bottom. Gently bow the
Diamond Shield™ toward you and insert the top of
the Diamond Shield™ into the top channel.
3. Install the left and right molding clips by pressing
them into the opening, starting at a corner.
Do not force the clip. The clip will slide
into place. This completes the Diamond
Shield™ installation.
To remove the Diamond Shield™, reverse
the order of the above process.
Diamond Shield™ for the models WS-
48511 and WS-55711 comes installed by
the factory.
21
3
Diamond Shield™ Installation for Models WS-48511,
WS- 55711, WS-65711, WS-65712 and WS-73711
