These inputs are compatible with component
video signals from standard DVD players and
other equipment sending a standard NTSC
component video signal (480i). These inputs are
also compatible with newer DVD players sending a
progressive NTSC component video signal (480p).
Component-1 and Component-2 Inputs
Input Levels and Timing with
Component Video
EIA - 770.1 and EIA - 770.2 Standard Levels &
Timing
Y = 1.0Vp-p (includes sync) 75-Ohms
Pr = 700mVp-p, 75-Ohms (can also receive
signals from outputs labeled R-Y and Cr)
Pb = 700mVp-p, 75-Ohms (can also receive
signals from outputs labeled B-Y and Cb)
Input Levels and Timing When
Used With HD Component Video
Signals
EIA - 770.3 Standard Levels and Timing
Y = 1.0Vp-p (includes sync) 75-Ohms
Pr = 700mVp-p, 75-Ohms
Pb = 700mVp-p, 75-Ohms
H = Not Used
V = Not Used
Input Levels and Timing When Used
With RGB Video Signals
G = 700mVp-p (no sync), 1Vp-p (with sync)
75-Ohms
R = 700mVp-p, 75-Ohms
B = 700mVp-p, 75-Ohms
H = 4Vp-p+/-1.0v, 75-Ohms
(when using separate H and V sync)
V = 4Vp-p+/-1.0v, 75-Ohms
(when using separate H and V sync)
VGA Input
This input will accommodate most computers
capable of supporting a VGA monitor. The only
compatible display resolution is 640x480. The sync
rate is 60 Hz. SVGA and XVGA resolutions are not
supported.
INP-DTV
This input is compatible with most standard DTV
and satellite receivers with component video
(YPbPr) outputs. Compatible DTV signals are
SDTV 480i/480p, and HDTV 1080i. All other DTV
signals, such as 720p, need to be converted by the
DTV receiver to one of the compatible signal types.
Please check the DTV receiver specifications before
connecting.
This input is compatible with some DTV receivers
using RGB with sync on green or with “separate H
and V sync”. Compatible DTV signals are SDTV
480i, 480p, and HDTV 1080i. All other DTV signals,
such as 720p, need to be converted by the DTV
receiver to one of the compatible signal types.
Industry standards for DTV RGB signals (systems,
synchronization, timing, and signal strengths) are
not currently established. These inputs will not be
compatible with all DTV receivers that offer RGB.
If your DTV receiver offers both DTV component
video signals and DTV RGB signals, we suggest
you use the DTV component video signals. Check
the DTV receiver specifications before connecting.
NetCommand™ IEEE 1394 & HAVi System Compatibility
This television is designed to conform to IEEE 1394 AV/C and HAVi Software standards in effect at the
time of development. This exciting new networking and control technology is designed to provide high-
performance digital connections and product control, making products easier to use.
At the time of development, only one other product was available for compatibility testing - the Mitsubishi
HD VCR, model HS-HD2000U. This D-VHS VCR is fully compatible with this TV.
As other manufacturers produce products that use IEEE 1394 AV/C and HAVi, they will be responsible for
the development of their products to meet the standards of the technology, as well as compatibility testing
with other products. Mitsubishi cannot be responsible for their efforts, and therefore cannot promise
compatibility with these other products. Any compatibility problems with other manufacturers products
should be brought to the attention of those manufacturers.
