WorldPhone – Chapter 3. Telefax Service 3.1

General

The WorldPhone provides access to a telefax service at a transmis-
son rate of 2.4 Kbps.

Limitations

The WorldPhone is fully compatible with the world’s leading telefax
machines and telefax software standards. However, transmission
may not be possible through some of the telefax machines available
on the market. Please check with your Net service provider before
purchasing a telefax for use with the WorldPhone.

Installation

Connect the telefax cable to the FAX port on the WorldPhone tel-
ephone unit. For wiring details, see

appendix B – Connecting up

optional equipment

Verify that the FAX port is configured for telefax service, see
"

Advanced functions: Port configuration

" in chapter 2. Operation.

Figure 3.1 Telefax communication with the WorldPhone.

Setting up

WorldPhone connector panel

5 4 3 2 1

6 7 8 9
