WorldPhone – Chapter 1. Getting Started 1.13
General
WorldPhone Marine comprises:
•
Above Deck Equipment – ADE
including stabilized antenna and RF transceiver.
•
Below Deck Equipment – BDE
including Telephone Unit and Power Supply.
A single coax cable links the ADE and BDE.
Figure 1.7 WorldPhone Marine terminal.
ADE
BDE
Antenna Unit
Antenna
coax cable
Telephone Unit
Power Supply
NT in AOR–E
