WorldPhone – Chapter 5. Appendices B-9
Appendix B – Installation of Voyager Antenna
Installation of Voyager
Antenna
Antenna Unit
The Antenna Unit should be installed so that severe vibration and
shock are avoided.
The equipment is supplied with a magnetic mounting bracket for
installation on cars with magnetic-holding roof top.
Mounting option:
Load Carrier Base Assembly for installation on cars with non-
magnetic roof material, or for installation on trains.
See illustration on next page.
Coax cable
A 5 metre coaxial cable type GO2232D (QRPM 911086-5000) is
supplied as standard.
Telephone Unit (TPU) and Power Supply (PS)
The PS is provided with holes for mounting on wall or dash board with
the TPU snapped on top of PS by fastening clips. A tripod mount
allows the unit to be mounted on the optional suction adapter.
The TPU may be installed separately by using 3 metre extension
cables between PS and TPU:
•
coaxial cable, QRPM 911087-3000
•
DC cable, QRPM 911079-3000
Source of energy
The equipment operates from 10 to 32 Volts DC from any 12V or 24V
battery.
Installation of Voyager Antenna
