WorldPhone – Chapter 5. Appendices

B-19

Appendix B – Installation of Provident Antenna cont’d

Optional bracket

Installation of Provident

Antenna cont’d

N-connector
(male)

Fastened
using
existing
hexagon
screws

Rear side of antenna

“Pigtail” QRPM 911059.1000

N-connectors

N-connector
(female)

Coax connector

Optional antenna cable
