Miller Electric IH - Manual (Page 40)

OM-203 185 Page 36
Single File With No Batch Name
scrn6
Data is continuously stored in the recorder.
If a batch was not started, the temperature
data is still recorded. The Job# (Batch
Name), User, Comments and Recorder ID
are not recorded.
The file name would consist of:
Group_Descriptor ∼ Time/Date_stamp.uhh
(no Batch Name).
The file creation time can be found using
the Detail Button.
Select the desired file.
Select “Open”.
scrn7
Enter the Job# (Batch Name) in
the field next to “Select or Enter
Instrument tag:”
This is the “File name” the
information will be stored in.
If a batch was not started, enter the
Job# (Batch Name) in the field next
to “Enter Batch Name if Required:”
as well.
Select “Start Transfer”.
Proceed to “New Instrument”
pop-up window (top of page 37).
