OM-203 185 Page 16
SECTION 6 − SETUP AND OPERATION
6-1. Safety Equipment
Wear the following during
operation:
1. Dry, Insulating Gloves
2. Safety Glasses With Side
Shields
DO NOT wear rings or watches
during operation.
sb3.1* 1/94
1 2
6-2. IH/TS Setup
6-2-1. Select Power Source
Energize the power source, cooler, and IH/TS. A power source selection will appear in the top right corner of the
IH/TS front panel Parameter Display. Press the recessed Power Source Select button on the IH/TS rear panel to
toggle through and select the appropriate power source maximum output. This selection will provide the proper out-
put scaling in the parameter display screen for the power source that is attached to the IH/TS.
0 . 0 K W P w r P S 2 5
0 A m p s ( r m s )
0 V o l t s ( r m s )
1 2 . 5 K H s F r e q u e n c y
Parameter Display
Power Source Max Output
