2. ih/ts rear panel – Miller Electric IH User Manual
Page 18
OM-203 185 Page 14
5-2. IH/TS Rear Panel
Y Keep all panels, doors, and
covers closed and secure
during programming.
1. Thermocouple Connectors
2. On/Off Power Switch
3. 115 VAC Power Cord
4. 14-Pin Receptacle
5. Coolant Flow Switch “IN”
Fitting
6. Coolant Flow Switch “OUT”
Fitting
7. Power Source Select Switch
8. Network Connection
Ref. 803 004-A
2
3
4
5
6
8
7
1
