MaxNAS Owner’s Manual 10
7. Visual and Audible Indicators
The MaxNAS has an LCD panel, LEDs, and a buzzer to inform the user of the overall health
and function of the unit. The following chart describes the various conditions indicated:
Indicator Normal Status Problem Indication
Firmware LED
Glows amber at boot or firmware
update. Dark after.
Dark at boot
LAN1 LED
Blinks green when there is network
activity on the LAN 1 port. A steady
green glow means there is a link but
no activity.
LED does not light up (no link)
LAN2 LED
Blinks green when there is network
activity on the LAN 1 port. A steady
green glow means there is a link but
no activity
LED does not light up (no link)
USB Copy LED
Glows blue during USB copy
operation
N/A
System Error LED Off
Glows red to indicate system fault. Log into the
management GUI for further information
Power Button LED
Glows blue on Power Up
Blinks blue on eSATA access
LED does not light up on power
Disk drive power LED Glows blue LED does not light up
Disk Activity/Fault
LED
Off/ blinks green during hard drive
read and write activity
Blinks red to indicate disk drive error
8. Hot plug Drive Replacement
In the event of a drive failure, the RAID subsystem supports the ability to hot-swap drives
without powering down the system. A disk can be disconnected, removed, or replaced with a
different disk without taking the system off-line. In a fault tolerant array, the RAID rebuilding
will proceed automatically in the background (see chapter 5, “Understanding RAID” for more
information.)
A drive failure will illuminate amber the Disk Activity/Fault LED on the affected drive canister.
To replace a drive, please follow these steps:
1. Make sure the drive locking mechanism (see page 9, “The MaxNAS Interface components”)
is in the up-down position (use the included key to turn the mechanism.)
2. Click down on the drive release latch (see page 9, “The MaxNAS Interface components”) to
release the drive tray.
3. Gently pull out the disk drive tray handle and slide out the drive tray.
4. To replace: Slide in the replacement drive tray with the tray handle open. When the tray is
slid all the way into the MaxNAS, push the tray handle closed.
IMPORTANT: NEVER remove a drive tray without replacing it. Operating the RAID with a drive tray
missing will disrupt airflow and may cause the MaxNAS to fail.
!
