CHAPTER 18: MODBUS PROTOCOL
MODBUS PROTOCOL
MULTILINK ML1200 MANAGED FIELD SWITCH – INSTRUCTION MANUAL
18–9
0128
Port 2: Number of 128 to 255 byte
frames received/sent
0 to
4294967295
1
F9
0
012A
Port 2: Number of 256 to 511 byte
frames received/sent
0 to
4294967295
1
F9
0
012C
Port 2: Number of 512 to 1023 byte
frames received/sent
0 to
4294967295
1
F9
0
012E
Port 2: Number of 1023 to maximum
byte frames received/sent
0 to
4294967295
1
F9
0
0130
Port 2: Number of MAC error packets
0 to
4294967295
1
F9
0
0132
Port 2: Number of dropped received
packets
0 to
4294967295
1
F9
0
0134
Port 2: Number of multicast frames
sent
0 to
4294967295
1
F9
0
0136
Port 2: Number of broadcast frames
sent
0 to
4294967295
1
F9
0
0138
Port 2: Number of <64 byte fragments
with good CRC
0 to
4294967295
1
F9
0
013A
Port 3: Number of bytes received
0 to
4294967295
1
F9
0
013C
Port 3: Number of bytes sent
0 to
4294967295
1
F9
0
013E
Port 3: Number of frames received
0 to
4294967295
1
F9
0
0140
Port 3: Number of frames sent
0 to
4294967295
1
F9
0
0142
Port 3: Total bytes received
0 to
4294967295
1
F9
0
0144
Port 3: Total frames received
0 to
4294967295
1
F9
0
0146
Port 3: Number of broadcast frames
received
0 to
4294967295
1
F9
0
0148
Port 3: Number of multicast frames
received
0 to
4294967295
1
F9
0
014A
Port 3: Number of frames with CRC
error
0 to
4294967295
1
F9
0
014C
Port 3: Number of oversized frames
received
0 to
4294967295
1
F9
0
014E
Port 3: Number of bad fragments
received (<64 bytes)
0 to
4294967295
1
F9
0
0150
Port 3: Number of jabber frames
received
0 to
4294967295
1
F9
0
0152
Port 3: Number of collisions occurred
0 to
4294967295
1
F9
0
0154
Port 3: Number of late collisions
occurred
0 to
4294967295
1
F9
0
0156
Port 3: Number of 64-byte frames
received/sent
0 to
4294967295
1
F9
0
0158
Port 3: Number of 65 to 127 byte
frames received/sent
0 to
4294967295
1
F9
0
015A
Port 3: Number of 128 to 255 byte
frames received/sent
0 to
4294967295
1
F9
0
015C
Port 3: Number of 256 to 511 byte
frames received/sent
0 to
4294967295
1
F9
0
015E
Port 3: Number of 512 to 1023 byte
frames received/sent
0 to
4294967295
1
F9
0
Table 18–1: Modbus memory map (Sheet 6 of 33)
Address
Description
Range
Step
Format
Default
