Free-wheel Configuration for
Winching
Chock the wheels to prevent the machine from
rolling.
Release the non-steer wheel brakes by turning
over the drive hub disconnect caps (see below).
Be sure the winch line is properly secured to the
drive chassis tie points and the path is clear of all
obstructions.
Reverse the procedures described to re-engage the
brakes.
Note: Towing the Genie Z-45/25 or the Z-45/25J is
not recommended. If the machine must be towed,
do not exceed 2 mph / 3.2 km/h.
Transport and Lifting Instructions
Transport Instructions
Observe and Obey:
The transport vehicle must be parked on a level
surface.
The transport vehicle must be secured to
prevent rolling while the machine is being
loaded.
Be sure the vehicle capacity, loading surfaces
and chains or straps are sufficient to withstand
the machine weight. See the serial plate for the
machine weight.
Be sure the turntable is secured with the
turntable rotation lock before transporting. Be
sure to unlock the turntable for operation.
Disengage
Position
Engage
Position
