Genie Z-45 - Manual (Page 23)

Part No. 82600 Genie Z-45/25 & Genie Z-45/25J 21
Operator's Manual Second Edition · Second Printing
42 Lower the secondary boom to the stowed
position.
43 Extend the primary boom approximately
1 foot / 30 cm.
44 Slowly move the drive control handle to the full
drive position.
Result: The maximum achievable drive speed
with the primary boom extended should not
exceed 6 in / 15 cm per second.
45 Retract the boom to the stowed position.
If the drive speed with the primary boom raised, the
secondary boom raised or the primary boom
extended exceeds 6 int / 15 cm cm per second,
immediately tag and remove the machine from
service.
Test the Oscillate Axle
(oscillating axle-equipped models)
46 Start the engine from the platform controls.
47 Drive the right steer tire up onto a 6 inch /
15 cm block or curb.
Result: The three remaining tires should stay in
firm contact with the ground.
48 Drive the left steer tire up onto a 6 inch /
15 cm block or curb.
Result: The three remaining tires should stay in
firm contact with the ground.
49 Drive both steer tires up onto a 6 inch /
15 cm block or curb.
Result: The non-steer tires should stay in firm
contact with the ground.
FUNCTION TESTS
