26 Genie Z-45/25 & Genie Z-45/25J Part No. 82600
Operator's Manual Second Edition · Second Printing
OPERATING INSTRUCTIONS
Auxiliary Controls
Use auxiliary power if the primary power source
(engine) fails.
1 Turn the key switch to ground or platform
control.
2 Pull out the red Emergency Stop button to the
on position.
3 Press down the foot switch when operating the
auxiliary controls from the platform.
4 Simultaneously hold auxiliary
power switch on and activate the
desired function.
The drive and steer functions will not operate with
auxiliary power.
Operation from Ground
1 Turn the key switch to ground control.
2 Pull out the red Emergency Stop button to
the on position.
3 Gasoline/LPG models: Choose fuel by moving
the fuel select switch to the desired position.
4 Start the engine.
To Position Platform
1 Hold the function enable switch to
either side.
2 Move the appropriate toggle switch according to
the markings on the control panel.
Drive and steer functions are not available from the
ground controls.
Machines equipped with Platform Level Control
Disable Function: The platform level toggle switch
will not operate when the primary boom is raised
past the drive speed limit switch.
Operation from Platform
1 Turn the key switch to platform control.
2 Pull out both ground and platform red
Emergency Stop buttons to the on position.
3 Gasoline/LPG models: Choose fuel by moving
the fuel select switch to the desired position.
4 Start the engine. Do not press down the foot
switch when starting the engine.
To Position Platform
1 Press down the foot switch.
2 Slowly move the appropriate function control
handle or toggle switch according to the
markings on the control panel.
Machines equipped with Platform Level Control
Disable Function: The platform level toggle switch
will not operate when the primary boom is raised
past the drive speed limit switch.
To Steer
1 Press down the foot switch.
2 Slowly move the control handle in the direction
indicated by blue or yellow triangles
OR press the thumb rocker switch located on
top of the drive control handle.
Use the color-coded direction triangles on the
platform controls and the drive chassis to identify
the direction the wheels will turn.
