8 Genie Z-45/25 & Genie Z-45/25J Part No. 82600
Operator's Manual Second Edition · Second Printing
1 3
6 Drive speed select switch
7 Diesel models: Glow plug switch (if equipped)
8 Engine start switch
9 Engine idle (rpm) select switch
10 Gasoline/LPG models: Gasoline/LPG
select switch
Platform Control Panel
1 Horn button
2 Platform level switch
3 Platform rotate switch
4 Z-45/25J models only: Jib boom up/down switch
5 Auxiliary power switch
2
CONTROLS
4 5 6
17 18 20 19
