Grizzly G9953ZX User Manual
Page 68
-66-
Ultimate Series Jointers
222 PSS01M
SET SCREW M6-1.0 X 10
223 PSS03M
SET SCREW M6-1.0 X 8
224 PB22M
HEX BOLT M8-1.25 X 50
225 PW07
FLAT WASHER
5
⁄
16
"
226 PN01M
HEX NUT M6-1.0
227 PB47M
HEX BOLT M6-1.0 X 40
228 PB52M
HEX BOLT M6-1.0 X 35
229 PSB48M
CAP SCREW M6-1. X 35
230 P4815230
PLATE
231 P4815231
ROD
232 P4815232
SUPPORT COLLAR (RIGHT)
233 P4815233
SUPPORT COLLAR (LEFT)
234 P4815234
ROD
235 P4815235
FENCE ADJUSTMENT ARM
236 P4815236
FENCE BRACKET BASE
237 P4815237
FENCE SUPPORT SEAT
238 P4815238
ROD
239 P4815239
FENCE
240 P4815240
ROTARY GEAR TUBE
241 PSB06M
CAP SCREW M6-1. X 25
301 P4815301
INFEED TABLE
302 P4815302
RIGHT SOUND DAMPENER
303 P4815303
TABLE SUPPORT ROD
304 PN32M
HEX NUT M14-2.0
305 PLW08M
LOCK WASHER 14MM
306 PSB06M
CAP SCREW M6-1. X 25
307 P4815307
DUST COVER
308 PB02M
HEX BOLT M6-1. X 12
309 PSB66M
CAP SCREW M8-1.25 X 65
310 PN03M
HEX NUT M8-1.25
311 PB09M
HEX BOLT M8-1.25 X 20
312 P4815312
ROD (LONG)
313 P4815313
ROD SPRING
314 PW01
FLAT WASHER
1
⁄
2
"
315 PW02
FLAT WASHER
3
⁄
8
"
316 PN08
HEX NUT
3
⁄
8
-16
317 P4815317
OUTFEED TABLE
318 P4815318
ROD (SHORT)
401 P4815401
RETURN CASING
402 P4815402
CUTTERHEAD GUARD
403 P4815403
RETURN SHAFT
404 PSB14M
CAP SCREW M8-1.25 X 20
405 PSB06M
CAP SCREW M6-1. X 25
501 P4815501
LIFTING FIXING SEAT
502 P4815502
LIFTING HANDWHEEL
503 P4815503
GEAR
504 P4815504
LIFTING COLLAR
505 P4815505
LIFTING ROD
506 P4815506
GEARED COLLAR
507 P4815507
LIFTING GEAR
508 P4815508
RING
509 P4815509
RING
510 P4815510
HANDWHEEL PLATE
511 P4815511
KNOB BOLT M10-1.5 X 20
512 P4815512
HANDLE
513 PB32M
HEX BOLT M10-1.5 X 25
514 PN02M
HEX NUT M10-1.5
515 PSS23M
SET SCREW M4-0.7 X 10
516 P4815516
OILER
3
⁄
16
”
517 PK20M
KEY 5 X 5 X 15
518 PLW01
LOCK WASHER
5
⁄
16
"
519 PB07M
HEX BOLT M8-1.25 X 25
520 PB58
HEX BOLT
3
⁄
8
-16 X 2
521 PN08
HEX NUT
3
⁄
8
-16
522 P4815522
HEX COLLAR
523 PSS02M
SET SCREW M6-1.0 X 6
601 P4815601
ROD
602 P4815602
HANDLE
603 P4815603
BRAKE CASING
604 P4815604
SPRING PIN
605 P4815605
SPRING
606 PSS02M
SET SCREW M6-1.0 X 6
701 P4815701
MOTOR 7
1
⁄
2
HP (3-PHASE)
702 P4815702
PULLEY
703 PLW04
LOCK WASHER
3
⁄
8
"
704 PB01M
HEX BOLT M10-1.5 X 30
705 PN02M
HEX NUT M10-1.5
706 PW01
FLAT WASHER
1
⁄
2
"
707 PB102M
HEX BOLT M12-1.75 X 25
708 PK57M
KEY 7 X 7 X 65
709 PSS08
SET SCREW
5
⁄
16
-18 X
1
⁄
2
710 P4815710
MOTOR PLATE
711 PVA50
V-BELT A-50 4L500
801 P9953801
STOP RING
802 P9953802
STOP RING ROD
803 PSB24M
CAP SCREW M5-.8 X 16
804 P9953804
THREADED KNOB
3
⁄
8
"
805 PN02
HEX NUT
5
⁄
16
-18
806 PW06
FLAT WASHER
1
⁄
4
"
807 PLW02
LOCK WASHER
1
⁄
4
"
901
P9860ZX801
CAP SCREW M6-1.0 x 13
902 H2334
INDEXABLE CUTTER
Ref#
Part#
Description
Ref#
Part#
Description
