Grizzly G9953ZX - Manual (Page 56)

-54- Ultimate Series Jointers
1 P9953001 BASE
2 P9953002 FENCE SEAT
3 P9859005 TABLE SUPPORT
4 P9859004 TABLE LIFTING ARM
5 P9859010 LIFTING ARM
6 P9953006 DUST HOOD
7 P9953007 LEFT REAR HOUSING
8 P9953008 TABLE SPINDLE
9 P9953009 RIGHT REAR HOUSING
10 P9953010 FRONT HOUSING
11 PW07 FLAT WASHER 5 ⁄
16
"
12 PB09M HEX BOLT M8-1.25 X 20
13 P9953013 DUST CHUTE
14 P9859011 BASE REAR COVER
15 PS24M PHLP HD SCR M6-1.0 X 10
16 PSB26M CAP SCREW M6-1.0 X 12
17 PW02 FLAT WASHER 3 ⁄
8
"
18 P9859029 LOCK KNOB
19 P9859033 STOP COLLAR
20 PSS20M SET SCREW M8-1.25 X 8
21 PW01 FLAT WASHER 1 ⁄
2
"
22 PB12M HEX BOLT M12-1.75 X 55
23 P9859014 SWITCH (GREEN)
24 P9859015 SWITCH (RED)
25 P9859016 SWITCH (WHITE)
26 PS14M PHLP HD SCR M6-1 X 12
27 P9953027 SWITCH PLATE
28 P9953028 SWITCH BOX
39 P9953039 MAG. CONT. CN-25 220V
39 P9953ZXF039 MAG. CONT. CN-18 220V
40 P9953040 OVLD. RELAY RHN-18/32A
40 P9953ZXF040 OVLD. RELAY RHN-18/17A
41 P9953041 LIGHT BULB 220V
42 P9953ZXF042 440V CONVERSION KIT
101 P9953101 CUTTERHEAD
102 P9953102 HEAD AXLE BOX (R.H.)
103 P9953103 HOUSING
104 P9953104 BEARING 6206-VV
105 P9953105 BEARING 6208-VV
106 P9953106 DUST COVER
107 P9953107 BRAKE NUT
108 P9953108 DUST COVER
109 P9953109 BEARING LOCK NUT
110 P9953110 PULLEY
111 P9953111 BRAKE PLATE
112 P9953112 WHEEL PLATE
112 P9953ZX112 PULLEY LOCK NUT
113 PS11M PHLP HD SCR M6-1.0 X 16
114 P9953114 CUTTER
115 P9953115 GIB
116 P9859121 SPECIAL SCREW
117 PLW04 LOCK WASHER 3 ⁄
8
"
118 PB01M HEX BOLT M10-1.5 X 30
119 PSB24M CAP SCREW M5-0.8 X 16
120 P9953120 CUTTER DOOR
121 PS21M PHLP HD SCR M4-0.7 X 15
122 P9953122 LOCK KNOB
123 PN06M HEX NUT M5-0.8
124 PSS09M SET SCREW M8-1.25 X 20
125 P9953125 NPT OIL FITTING 1 ⁄
8
"
132 P9953132 BRAKE PLATE
133 PSB40M CAP SCREW M8-1.25 X 35
134 PN03M HEX NUT M8-1.25
135 P9953135 BRAKE PLATE
136 P9953136 FIGURE SWITCH
137 P9953137 BRAKE PLATE
138 PS01 PHLP HD SCR #10-24 X 1 ⁄
2
"
139 PW03 FLAT WASHER #10]
140 PS06 PHLP HD SCR #10-24 X 3 ⁄
8
"
141 PSB11M CAP SCREW M8-1.25 X 16
142 PN04M HEX NUT M4-0.7
143 PS64M PHLP HD SCR M4-0.7 X 65
144 PB47M HEX BOLT M6-1.0 X 40
145 PN01M HEX NUT M6-1.0
146 P9953146 SPRING
201 P9953201 TUBE SEAT
202 P9953202 BASE (LEFT)
203 P9953203 BASE (RIGHT)
204 P9953204 PLATE
205 PSB71M CAP SCREW M10-1.5 X 60
206 PLW01 LOCK WASHER 5 ⁄
16
"
207 PSB05M CAP SCREW M8-1.25 X 50
208 PSB72M CAP SCREW M10-1.5 X 30
209 PW06 FLAT WASHER 1 ⁄
4
"
210 PSB04M CAP SCREW M6-1.0 X 10
211 P9953211 GEAR SHAFT
212 P9953212 HANDWHEEL
213 PN02 HEX NUT 5 ⁄
16
"-18
214 P9953214 HANDLE
215 PSS01 SET SCREW 5 ⁄
16
"-18 X 1"
216 PN03M HEX NUT M8-1.25
217 PSS21M SET SCREW M8-1.25 X 25
218 P9953218 LOCK LEVER
219 P9859221 KNOB
220 P9859220 ADJUSTMENT ROD
221 PW03M FLAT WASHER M6
222 PSS01M SET SCREW M6-1.0 X 10
223 PSS03M SET SCREW M6-1.0 X 8
Ref# Part# Description Ref# Part# Description
