-13- Ultimate Series Jointers
Unpacking
The Model G9953 16" Ultimate Series Jointers
and the Model G4815 20" Ultimate Series Jointer
are shipped from the manufacturer in a carefully
packaged crate. If there are any signs of crate
damage after you have signed for delivery, imme-
diately call our customer service for advice.
The Ultimate Series
Jointers are heavy
machines. DO NOT
over-exert yourself
while unpacking or
moving your machine
— you will need assis-
tance and power equip-
ment. Serious personal
injury may occur if safe
moving methods are
not followed.
Parts Inventory
Models G9953ZX, G9953ZXF, & G4815: Qty
• Fence Assembly 1
• Air Pressure Gauge 1
• Air Pressure Regulator 1
• Push Blocks 2
• Air Wrench 1
• T-20 Torx® Screwdriver 5
• Extra Carbide Cutters - 14 x 14 x 2mm 10
• T-Handle For Torx® Bits 1
• Hardware Bag Contents:
—Regulator Mounting Bracket 1
—Air Quick Disconnect 1
—Phillips Head Bits 2
—T-20 Torx® Bits 15
—Cap Screws M6-1.0 x 14 30
Model G9953: Qty
• Fence Assembly 1
• Push Blocks 2
• Allen Wrench Set 1
• Knife Setting Gauge 1
• Open End Wrench 1
Figure 10. Spiral Cutterhead Accessories.
Figure 11. Model G9953 accessories.
Sharp edges on metal
parts may cause person-
al injury. Examine the
edges of all metal parts
before handling.
NOTICE
The photos shown in this manual are of the
Model G4815 unless otherwise noted.
SECTION 5: SET UP
