Grizzly G9953ZX - Manual (Page 67)

Ultimate Series Jointers -65-
1 P4815001 BASE
2 P4815002 DUST HOOD
3 PS24M PHLP HD SCR M6-1.0 X 10
4 P4815004 BRACKET
5 P4815005 BRACKET
6 PW04M FLAT WASHER 10MM
7 PLW06M LOCK WASHER 10MM
8 PSB70M CAP SCREW M10-1.5 X 45
9 PSB65M CAP SCREW M10-1.5 X 70
10 P4815010 LONG SHAFT
11 P4815011 LIFTING BRACKET (LEFT)
12 P4815012 SUPPORT BRACKET
13 P4815013 LIFTING BRACKET (RIGHT)
14 P4815014 FRONT PLATE
15 PN02M HEX NUT M10-1.5
16 P4815016 FRONT COVER KNOB
17 PW03M FLAT WASHER 6MM
18 P4815018 LEFT REAR PLATE (SHORT)
19 P4815019 RIGHT REAR PLATE (LONG)
20 P4815020 REAR COVER FIXING KNOB
21 P4815021 BASE REAR COVER
22 PW06M FLAT WASHER 12MM
23 PB12M HEX BOLT M12-1.75 X 55
24 P4815024 START HANDLE
25 PB60 HEX BOLT 3 ⁄
8
-16 X 3
26 P4815026 SWITCH (GREEN)
27 P4815027 SWITCH (RED)
28 P4815028 SWITCH (WHITE)
29 PS14M PHLP HD SCR M6-1 X 12
30 P4815030 SWITCH PLATE
31 P4815031 ELECTRIC BOX
32 P4815032 STOP CLAW FIXED RING
33 PSS20M SET SCREW M8-1.25 X 8
34 P4815034 MACHINE ID LABEL
35 PLABEL-11 SAFETY GLASSES LABEL
36 P4815036 PUSH BLOCK LABEL
37 PLABEL-24 Z SERIES LABEL
38 PLABEL-8 CAST IRON LOGO
39 P4815039 MAG. CONT. CN-18 220V
40 P4815040 OVLD. RELAY RHN-18/23A
41 P4815041 LIGHT BULB 220V
42 P4815042 440V CONVERSION KIT
101 P4815101 CUTTERHEAD
102 P4815102 MOUNTING BRACKET
103 P4815103 MOUNTING BRACKET
104 P6206 BEARING 6206
105 P6208 BEARING 6208
106 P4815106 DUST COVER
107 P4815107 BRAKE COLLAR
108 P4815108 DUST COVER
109 P4815109 BEARING LOCK COLLAR
110 P4815110 CUTTERHEAD PULLEY
112 P4815112 PULLEY LOCK NUT
113 PLW04 LOCK WASHER 3 ⁄
8
"
114 PB01M HEX BOLT M10-1.5 X 30
115 PSB24M CAP SCREW M5-.8 X 16
116 P4815116 REAR CUTTERHEAD DOOR
117 PS21M PHLP HD SCR M4-.7 X 15
118 P4815118 HANDLE
119 PN06M HEX NUT M5-0.8
120 PSS09M SET SCREW M8-1.25 X 20
121 P4815121 OIL FEEDER
122 P4815122 BRAKE PLATE
123 PSB40M CAP SCREW M8-1.25 X 35
124 PN03M HEX NUT M8-1.25
125 P4815125 BRAKE PLATE
126 P4815126 FIGURE SWITCH
127 P4815127 BRAKE PLATE
128 PS01 PHLP HD SCR #10-24 X 1 ⁄
2
"
129 PW03 FLAT WASHER #10
130 PS06 PHLP HD SCR #10-24 X 3 ⁄
8
"
131 PSB11M CAP SCREW M8-1.25 X 16
132 PN04M HEX NUT M4-0.7
133 PS64M PHLP HD SCR M4-.7 X 65
134 PB47M HEX BOLT M6-1.0 X 40
135 PN01M HEX NUT M6-1.0
136 P4815136 SPRING
201 P4815201 FENCE TUBE BRACKET
202 P4815202 BASE SPINDLE (LEFT)
203 P4815203 BASE SPINDLE (RIGHT)
204 P4815204 CUTTERHEAD TOP PLATE
205 PSB71M CAP SCREW M10-1.5 X 60
206 PLW01 LOCK WASHER 5 ⁄
16
"
207 PSB05M CAP SCREW M8-1.25 X 50
208 PSB72M CAP SCREW M10-1.5 X 30
209 PW06 FLAT WASHER 1 ⁄
4
"
210 PS24M PHLP HD SCR M6-1.0 X 10
211 P4815211 ROTARY GEAR SHAFT
212 P4815212 HANDWHEEL
213 PN02 HEX NUT 5 ⁄
16
-18
214 P4815214 KNOB 5 ⁄
16
-18
215 PSS01 SET SCREW 5 ⁄
16
-18 X 1
216 PN03M HEX NUT M8-1.25
217 PSS21M SET SCREW M8-1.25 X 25
218 P4815218 KNOB BOLT 1 ⁄
2
-12 X 25
219 P4815219 THREADED KNOB 3 ⁄
8
"-16
220 P4815220 ADJUST SHAFT
221 PW03M FLAT WASHER 6MM
Ref# Part# Description Ref# Part# Description
