Grizzly G9953ZX - Manual (Page 19)

Ultimate Series Jointers -17-
To mount the pedestal switch:
Attach the pedestal switch (Figure 13) to the back
of the base with (4) M10-1.5 x 25 cap screws and
(4) M10 flat washers.
To attach dust collection hose to the dust
port:
Attach a 5" hose from your dust collection system
to the dust port (
Figure 14).
Figure 14. Dust collection hook-up.
Figure 13. Attaching pedestal switch.
Pedestal Switch Dust Collection
Pedestal Switch
Dust Port
