GXV3140 USER MANUAL

www.grandstream.com

SOFTWARE VERSION 1.0.0.44

[email protected]

SAVING THE CONFIGURATION CHANGES

After users makes changes to the configuration, press the “Save” button in the Configuration Menu. The
web browser will then display a message window to confirm the saved changes. Reboot the phone for the
new settings to take effect

.

REMOTE REBOOT

Press the “Reboot” button at the top right-hand corner of the configuration menu to reboot the phone
remotely. The web browser will then display a message window to confirm with the user if they wish to
reboot the phone or not. Click on “Yes” and the phone will reboot. Wait 30 seconds to log in again.

CONFIGURATION THROUGH A CENTRAL SERVER

The Grandstream GXV3140 can be automatically configured from a central provisioning system.

When the GXV3140 boots up, it will send TFTP or HTTP request to download a configuration file,
“cfg000b82xxxxxx”, where “000b82xxxxxx” is the MAC address of the GXV3140.

The configuration data can be downloaded from the central server via TFTP or HTTP/HTTPS. A service
provider or an enterprise with larger deployments of Grandstream devices can easily manage the
configuration and service provisioning of individual devices remotely from a central server.

Grandstream has a central provisioning system called GAPS (Grandstream Automated Provisioning
System). GAPS supports automatic configuration of Grandstream devices.

GAPS uses enhanced (NAT

friendly) TFTP or HTTP (thus no NAT issues) and other communication protocols to communicate with
each individual Grandstream device.

Grandstream provides GAPS service to VoIP service providers. GAPS can be used for either simple
redirection or with certain special provisioning settings. At boot-up, Grandstream devices by default point
to the Grandstream provisioning server (GAPS). Based on the unique MAC address of each device, GAPS
will provision the devices with redirection settings so that they will be redirected to customer’s TFTP or
HTTP server for further provisioning. Grandstream also provides the GAPSLITE software package which
contains our NAT friendly TFTP server and a configuration tool to facilitate the task of generating device
configuration files.

The GAPSLITE configuration tool is now free to end users. The tool and configuration templates are
available for download from

http://www.grandstream.com/configurationtool.html
