Gateway 600YG2 - Manual (Page 65)

60
Replacing Gateway 600YG2 Components
www.gateway.com
14
Insert the small flat-blade screwdriver or non-marring tool under the right
side of the indicator panel and gently pry it up about ¼ inch, then lift the
entire panel from the notebook.
15
Align the new indicator panel’s screw hole with the hole on the notebook,
then press the panel into place.
16
Replace the indicator panel’s shielding, then replace the screw.
17
Reassemble the notebook.
Caution Legal requirements dictate that a security screw (or other
means) be used to attach the mini-PCI cover to the chassis
in a manner that restricts end user access. End users are
strictly prohibited from having access to the wireless card.
Due to manufacturing process changes, Gateway 600YG2
notebooks manufactured after August 7, 2003 require a
Torx head security screw to attach the mini-PCI cover.
Caution Legal requirements dictate the mini-PCI cover be in place
during any and all operation of the notebook’s wireless
feature.
