Gateway 600YG2 - Manual (Page 42)

37
Replacing the hinge covers
www.gateway.com
Replacing the hinge covers
Tools you need to complete this task:
Screws removed during this task:
To replace the hinge covers:
1
Disconnect the AC adapter and modem and network cables and prepare
the notebook by following the instructions in
“Preparing your work space”
on page 4 .
2
Disconnect the notebook from the optional port replicator by following
the instructions in
“Disconnecting from the port replicator” on page 7 .
3
Turn the notebook over so the bottom is facing up.
4
Remove the main and optional secondary batteries by following the
instructions in
“Removing the batteries” on page 8 .
5
Turn the notebook over so the top is facing up.
6
Remove the keyboard cover by following the instructions in “Replacing
the keyboard cover” on page 28 .
7
Open the LCD panel all the way, so it lies flat on the table.
Flat-blade driver Scribe or non-marring tool - OR -
Phillips #0 screwdriver
4 chrome 2.5 × 5 mm
(hinge covers)
