Gateway 600YG2 - Manual (Page 17)

12
Replacing Gateway 600YG2 Components
www.gateway.com
To add or replace memory modules:
1
Disconnect the AC adapter and modem and network cables and prepare
the notebook by following the instructions in
“Preparing your work space”
on page 4 .
2
Disconnect the notebook from the optional port replicator by following
the instructions in
“Disconnecting from the port replicator” on page 7 .
3
Turn the notebook over so the bottom is facing up.
4
Remove the main and optional secondary batteries by following the
instructions in
“Removing the batteries” on page 8 .
5
Loosen the captive screw that secures the memory cover. (The screw cannot
be removed.)
6
Lift the screw side of the cover upward, then slide the cover out.
